GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage

Place of Origin : Guangdong, China

Brand Name : TSD

Packaging Details : Packed in anti-static bag each,a certain quantity in one carton

Supply Ability : 50000 Piece/Pieces per Month

MOQ : Negotiable

Price : Negotiable

Type : TFT LCD

Display Size : 1.77inch

Supplier Type : Manufacturer

Resolution : 128x160

Active Area : 28.03x35.04mm

Outline Dimension : 34x43.78x2.45mm

Interface Type : MCU 8bit

Driver IC : GC9106

Viewing direction : 6 O'clock

Backlight : 2LEDs, 40mA, 3.2V

Brightness : 220 Cd/m2

Operating Voltage : 2.8V

Port : Shenzhen/Hong Kong

Contact Now

GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
128*160 1.77 inch MCU 8bit Interface GC9106 20pin tft lcd display module panel
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
Item
Specification
Display Mode
1.77''/α-Si TFT/TN/
Transmissive/Normally White
Part NO.
TST018QQHG-13
Resolution
128x(RGB)x160
Outline Size
34x43.78x2.45mm
Active Area
28.03x35.04mm
View Direction
6 O'clock
Color Depth
65K
Interface
MCU 8-bit
Driver IC
GC9106
Backlight
2LEDs, 40mA, 3.2V
Surface Lumiannce
220nits
Input Voltage
2.8V
Operating Temperature
-20℃~70℃
Storage Temperature
-30℃~80℃
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
More detailed datasheet can be provided! Click here to contact us!
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
What TSD has?
1)TFT:
0.96''-13.3''(TN&IPS). Brightness can be designed per customer's requirement. Polarizer has TV, EWV, Ofilm. All kind of FPC design supported.

2)Passive:
display mode with TN, HTN, STN, FSTN, DFSTN, VA.
Structure has LCD Panel, COB, COG. Connection with Zebra, Pin, FPC, Rubber. Brightness can be designed per customer's requirement.

3)CTP:
we have standard one and also available to make the customization of with different size, shape, color, logo etc. Having G+G, G+F, G+F+F Structure. OCA and OCR Optical Bonding. Cover lens can add AR, AF,AG coating. Driver can be used FT, GT, Atmel,
ILITEK, ST...

4)HMI:
Supporting size 2.4'' 2.8'' 3.2'' 3.5'' 4.3'' 5.0'' 7.0'' 10.1'' Driver has BT8XX from FTDI and etc...
Control graphics and RTP and CTP and audio etc...
About us
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
Production Process
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
Application
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
Exhibition & Certificate
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
Packing & Delivery
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
FAQ
Q: How can i find the right product?
A: Please send us your requirements, we will recommend our standard products, if it’s not fit, we will do the necessary adjustment & customization.

Q: How to customize the product?
A: Customized procedures goes like this: Project scope clarification → Fill TSD Requirement Form → Engineering analysis → Cost→Evaluation → Customer confirmation → Providing drawing → Customer confirmation → Sampling → Customer approval → Mass production

Q: Do you accept sample order or small quantity order?
A: Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)

Q: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

Q: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and product)
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
GC9106 TFT LCD Module MCU 8bit Interface 1.77 Inch 2.8V Operating Voltage
